KAT DRILLING
1 / 5
| Diameter | Length | No. of Buttons | Button Size (mm) | Side Holes | Center Holes | Weight (kg) | |||
|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | Gauge | Center | ||||
| For 22 mm (7/8") hex Rod - 4°46' Taper (Short Skirt) | |||||||||
| 36 | 1 13/32" | 50 | 1 31/32" | 7 | 5x7 | 2x7 | 1 | 2 | 0.2 |
| For 22 mm (7/8") hex Rod - 4°46' Taper (Long Skirt) | |||||||||
| 33 | 1 5/16" | 71 | 2 5/32" | 7 | 5x8 | 2x7 | 1 | 1 | 0.3 |
| 36 | 1 13/32" | 71 | 2 5/32" | 7 | 5x9 | 2x7 | 1 | 1 | 0.3 |
| 41 | 1 5/8" | 71 | 2 5/32" | 7 | 5x7 | 2x7 | - | 2 | 0.3 |
| For 22 mm (7/8") hex Rod - 7° Taper (Long Skirt) | |||||||||
| 30 | 1 3/16" | 80 | 3 5/32" | 7 | 5x6 | 2x7 | 2 | 1 | 0.2 |
| 32 | 1 1/4" | 80 | 3 5/32" | 7 | 5x7 | 2x7 | 1 | 1 | 0.3 |
| 41 | 1 5/8" | 80 | 3 5/32" | 7 | 5x9 | 2x8 | 1 | 1 | 0.4 |
