High-Quality U95 Shearer Pick-Carbide Strips Manufacturers, Factory

1 / 2

High-Quality U95 Shearer Pick-Carbide Strips Manufacturers, Factory

Our products include all kinds of round cutter bit and flat cutter bits for excavate coal Machine. Such as U76, U82, U84, U85, U92, U94, U95, U118 S100,S135,S150,S160,S200 , B47K17H, B47K19H, B47K22H, B43K, B43H, BHR73 etc and coal bolting bit and coal bolting Rod.

Send Inquiry

Product Description

⚙

Alloy Steel Body: Manufactured using premium ASTM4140 (42CrMoA) material, featuring heat treatment to HRC38-42 hardness. This ensures high toughness and exceptional wear resistance.

Tungsten Carbide Tip: Created from low-pressure sintered carbide. Grades are specifically selected based on target project requirements to guarantee peak performance during operations.

Machine Compatibility: These products are engineered for a high feed rate, long service life, and minimized tool-changing intervals. Ideal for surface mining, underground mining, and tunneling.

We offer a comprehensive range of round cutter bits and flat cutter bits for coal excavation machinery. Available models include: U76, U82, U84, U85, U92, U94, U95, U118, S100, S135, S150, S160, S200, B47K17H, B47K19H, B47K22H, B43K, B43H, BHR73, as well as coal bolting bits and rods.

U95 Shearer Pick Specifications

General Product Information
Product Name	Coal Cutting Tools
Description	Rock drilling tools, construction drilling, mining tools, road milling tools, and shield cutters.
Material	Carbide Steel
MOQ	100 PCS
Available Types	U76, U82, U84, U85, U92, U94, U95, U118, S100, S135, S150, B47K19H, B47K22H, B43K, B43H, BHR73, etc.
Diameter Range	19mm - 70mm
Primary Use	Mining and Drilling
Color Options	Customized according to customer requests

Compatibility Guide

Our products are engineered to serve as high-quality replacements for industry-standard specifications, including:

19mm Round Shank: U43KHL, C21, U43KH, C24, U43K, C22, U43KL, C21HD, U43KHD

20mm Round Shank: U50KH, U50KL, U51KHL, U51KL

25mm Round Shank: U765XHD, AM476, U765HD, U73, UC765, AM765PKH, C31HD, C31, C32

30mm Round Shank: KS5, AM510FG, U119, U119HF, AM521HF, U85AUS, AM511, U85, U85HD, UR118

35mm Round Shank: U92, U92HD, U92HDL, U92K, U94, U94KHD, U92KHD, U92LR, U95, U95HD

30/38mm Round Shank: C7, U47, KSM1, U47HD, U47 52, U47GB, TS11, KSM7, C4, U44

52mm Round Shank: U200HF, AM956DB, AM962, U200, U200TS, AM941, AM941HF, AM942DB

Technical Parameters

Category	Model	Height (mm)	Diameter (mm)	Alloy Size (mm)	Tooth Sleeve (mm)
Shearer Pick	U47	157	Φ64	Φ19 / Φ14	Φ30
	U82	152	Φ50	Φ22 / Φ19	Φ30
	U84	139/142	Φ55/Φ50	Φ16 / Φ19	Φ30
	U95	182.5	Φ54	Φ23	Φ35
Roadheader Pick	S100	141/143	Φ53/Φ44.5	Φ22/Φ13/Φ12	Φ33.7
	S120	153/139	Φ70/Φ55/Φ50	Φ22 / Φ17	Φ38 / Φ30
	S135	155/157	Φ64/Φ62/Φ65	Φ25 / Φ23	Φ38 / Φ35
	S260	156/165	Φ80/Φ65	Φ34 / Φ25	Φ37.5 / Φ38
Rotary Excavator Pick	C31/25-12H	118	Φ33	Φ12	Φ25
	C34/25-19H	118	Φ47	Φ19	Φ25
	C50/30-19H	130.5	Φ50	Φ19	Φ30
	C60/30-22H	130.5	Φ60	Φ22	Φ30

Frequently Asked Questions

Q1: What materials are used for the body of the cutter bits?

The body is made of high-quality alloy steel ASTM4140 (42CrMoA), heat-treated to a hardness of HRC38-42 for superior toughness.

Q2: How is the tungsten carbide tip manufactured?

The tips are made using low-pressure sintering processes, with carbide grades specifically chosen to match the hardness and demands of the target project.

Q3: Are these tools compatible with different mining environments?

Yes, these tools are highly versatile and suitable for surface mining, underground mining, tunneling, and various excavation projects.

Q4: Can these bits replace other brand specifications?

Absolutely. Our products are designed to meet or exceed standard industry specifications, including replacements for 19mm to 52mm round shank tools.

Q5: What is the typical Minimum Order Quantity (MOQ)?

The standard MOQ for our coal cutting tools and picks is 100 pieces per order.

Q6: What is the benefit of the heat-treated alloy steel?

The heat treatment provides a perfect balance of hardness and wearability, ensuring a long service life and reducing the frequency of tool changes during heavy-duty operation.
