Taper button bit as small hole bit is different with thread button bit as long hole bit to use taper match with bit with rod to be used for air leg or hand held jack hammer driller in quarrying,and mining. Description :

(1)Connect shank Size: Φ19, Φ22, Φ25 at most

(2)Bit Diameter:Diameter 32mm,34mm,36mm, 38mm,40mm

(3)Tapered connection: 6 degree, 7 degree, 11 degree, 12 degree etc.

(4)Material︰Alloy Steel Bar 45CrNiMoV, Tungsten Carbide Tips YK05 or T6.

(5)Button Shape︰ Ballistic Face Type︰ Flat Face; Bit Body︰Standard

(6)Qty of button: 5,7, 8 pcs

(7)main market: India, Saudi, Chile, South Africa,stone country consume too much

Send Inquiry

Product Description

Tapered button bits are specialized small hole drill bits, distinct from thread button bits used for long holes. These bits utilize a taper match to connect with the drill rod, making them ideal for air leg or hand-held jack hammer drillers in quarrying and mining operations.

Technical Specifications

Connect Shank Size Φ19, Φ22, Φ25 (max)
Bit Diameter 32mm, 34mm, 36mm, 38mm, 40mm
Tapered Connection 6°, 7°, 11°, 12°, etc.
Material Composition Alloy Steel Bar 45CrNiMoV
Carbide Tips Tungsten Carbide YK05 or T6
Button Configuration 5, 7, 8 pcs Buttons

Design & Features

🎯
Face Type

Available in Ballistic Face and Flat Face designs for various rock formations.

🛠️
Bit Body

Standard robust bit body designed for high-efficiency energy transmission.

🌍
Global Standard

Widely utilized in major mining markets including India, Saudi Arabia, Chile, and South Africa.

The commitment to quality, efficiency, and innovation ensures that every tapered drill bit provides maximum value. By utilizing abundant resources and highly developed machinery, these products are designed for durability and high performance in demanding environments.

Frequently Asked Questions

What is the primary application for tapered button bits?
They are primarily used for small hole drilling in quarrying and mining, compatible with air leg or hand-held jack hammer drillers.
What materials are used in the manufacturing process?
The bits are made from high-quality Alloy Steel Bar (45CrNiMoV) and feature Tungsten Carbide Tips (YK05 or T6).
Which taper degrees are available for connection?
Common taper connections include 6 degree, 7 degree, 11 degree, and 12 degree options.
What are the available diameters for these drill bits?
The bit diameters range from 32mm to 40mm, including standard sizes like 34mm, 36mm, and 38mm.
How many tungsten carbide buttons are on each bit?
Depending on the specific requirements and size, the bits typically come with 5, 7, or 8 button pieces.
What face types are available for the button bits?
The bits are available in both Ballistic Face and Flat Face types to suit different drilling conditions.
