Bench and production drilling tools include rods, shank adapters, couplings and bits. We provide 9 main threads: R3212, R32, HL38, T38, T45, T51, T60, ST58 and ST68. They are compatible with button bits, cross bits and reaming products.
| Bit Type | Gauge Carbide | Front Carbide | Dimensions D | Flushing Hole | ||||
|---|---|---|---|---|---|---|---|---|
| No. | mm | No. | mm | mm | inch | Front | Side | |
| Button bit-T38 | 6 | 10 | 3 | 10 | 57 | 2 1/4" | 3 | 1 |
| Button bit-T38 | 6 | 11 | 3 | 11 | 64 | 2 1/2" | 3 | 1 |
| Button bit-T38 | 6 | 12.7 | 3 | 12.7 | 76 | 3" | 3 | 1 |
| Drop Center | 6 | 11 | 3/1 | 11/9.5 | 70 | 2 3/4" | 3 | 0 |
| Drop Center | 8 | 11 | 4/2 | 11/9.5 | 89 | 3 1/2" | 4 | 0 |
