Because of economy and powerful drilling capacity, down the hole hammer become an advanced drilling tool for drilling and mining industries. Down the hole hammers and drill bits are designed together to work in perfect unison, giving high penetration rates, long service life and low costs.
| COMPATIBILITY: QL6 / QL60, DHD, SD, MISSION Series | |||||||
|---|---|---|---|---|---|---|---|
| Type | Gauge Buttons | Front Buttons | Diameter | Weight (Kg) | |||
| No. | mm | No. | mm | mm | inch | ||
| DTH Bit | 8 | 16 | 8 | 16 | 152 | 6" | 23.9 |
| DTH Bit | 8 | 16 | 8 | 16 | 159 | 6 1/4" | 24.15 |
| DTH Bit | 8 | 16 | 10 | 16 | 165 | 6 1/2" | 25.2 |
| DTH Bit | 10 | 19 | 14 | 16 | 190 | 7 1/2" | 26.5 |
| DTH Bit | 10 | 19 | 14 | 16 | 203 | 8" | 31.8 |
| DTH Bit | 12 | 19 | 23 | 16 | 244 | 9 5/8" | 51 |
