Basic Specifications
Certification
CE, ISO 9001:2000, ISO 9001:2008
Tungsten Carbide
Yk05 or T6
Shank Adapter
CIR / DHD / M / QL / SD
Surface Treatment
Spray-Paint
Machine Type
Drilling Tools
Product Overview
Because of economy and powerful drilling capacity, down the hole hammer become an advanced drilling tool for drilling and mining industries. Down the hole hammers and drill bits are designed together to work in perfect unison, giving high penetration rates, long service life and low costs.
Key Features & Advantages
- Maximum Energy Transfer: Delivers maximum energy to drilling bit, ensuring fast drilling speed and low air consumption.
- Advanced Materials: Smooth performance and long service life due to high quality alloy steel and advanced processing technology.
- Easy Maintenance: Simple, reliable, and easy to assemble/disassemble inner structure.
- Multi-head Thread: Easy to depart bit from hammer via the connecting chuck and cylinder.
- High Compatibility: Fully interchangeable with standard DTH bits and drill pipes.
Primary Applications
- Water well drilling
- Mining & Mineral Exploration
- Bench drilling
- Oil well drilling
- Civil Engineering Applications
- High pressure drilling rigs
- Record breaking penetration projects
- Lowest cost per foot operations
Technical Data - DHD Series
| Bit Type |
Gauge Carbide |
Front Carbide |
Dimensions (D) |
Weight (Kg) |
| No. |
mm |
No. |
mm |
mm |
inch |
| DHD 3.5 |
8 |
11 |
6 |
11 |
85 |
3 3/8" |
4.2 |
| DHD 3.5 |
8 |
12 |
6 |
12 |
92 |
3 5/8" |
4.6 |
| DHD 3.5 |
8 |
12 |
7 |
12 |
100 |
3 15/16" |
4.95 |
| DHD 3.5 |
8 |
12 |
8 |
12 |
105 |
4 1/8" |
5.4 |
Size & Packaging
Package Type:
Wooden Case (30cm x 30cm x 30cm)
Standard Weight:
5.000kg (Gross)
Frequently Asked Questions
What shanks are compatible with these DTH bits?
Our bits are compatible with a wide range of shanks including CIR, DHD, M, QL, and SD adapters.
What materials are used in the manufacturing process?
We use high-quality Carbon Steel and Tungsten Carbide (Yk05 or T6 grade) to ensure maximum durability and wear resistance.
Do these hammers work with high-pressure rigs?
Yes, they are specifically designed for both low and high-pressure drilling rigs, providing excellent penetration rates.
What is the expected penetration speed increase?
Due to the advanced inner structure and energy delivery, these bits can penetrate 15% to 30% faster than standard alternatives.
Are the hammers easy to maintain?
Absolutely. The inner structure is simple and reliable, designed for easy assembly and disassembly to reduce downtime.
How are the products protected during shipping?
All drill bits and hammers are securely packed in robust wooden cases to prevent damage during transit.
