High-Quality High Quality Hex22/25-7 Degree 600-8000mm Taper Drill Steel Rod for Mining Quarrying Manufacturer, Factories

Customization:	Available
After-sales Service:	Repair or Replacement
Warranty:	6 Months

i

Basic Information

Model NO.

Taper Rod

Certification

ISO 9001:2000, ISO 9001:2008

Standard

GB

Surface Treatment

Spray-Paint

Manufacturing Process

Forging

Material

Carbon Steel

Degree

7/11/12

Machine Type

Drilling Tools

Color

Red, Black, Yellow, White

Material Quality

95crmo 55simnmo 40simncrnimo 23crni3mo D6a

HS Code

82071990

Production Capacity

500,000 PCS/Month

📦

Packaging & Delivery

Package Size

30.00cm * 30.00cm * 30.00cm

Package Gross Weight

5.000kg

Transport Package

Wooden Case or Bundles

⚙️

Product Description

Taper drill rod is used for rock drilling, blasting holes and other drilling works in the quarries, coal mines, traffic and other contractions. It works with taper drill bits and has different length for various applications.

Key Application Theory: Generally, light duty rock drills use a 7° taper or smaller angle, while heavy duty rock drills mainly use 11° or 12° taper angles. The taper drill rods and taper drill bits must share the same tapered degree for optimal performance.

We provide tapered rods in a full range of shank configurations and steel hex diameters for hand-held pneumatic drilling needs.

Steel grade

95CrMo (equiv. to SANDBAR20, C253, Z708, Sanbar23, 55SiMnMo)

Shank size

Hex 22mm×108mm, 22mm×159mm, 22mm×80mm, 25mm×108mm, 25mm×159mm

Taper Angles

4°46′, 6°, 7°, 11°, 12° degree etc.

Length Range

0.4m - 10m

📊

Technical Specifications

Shank hex. 22 mm (7/8") x 108 mm (4 1/4"). Rod hex. 22 mm (7/8). Flushing hole diameter 6.7 mm

ROD CROSS SECTION	Length (mm)	Length (foot/inch)	Weight approx. (kg)
4°46′ taper angle
22H	800	2′7½″	2.8
22H	1600	5′3″	5.3
22H	2000	6′6¾″	6.5
22H	2400	7′10½″	7.7
22H	3200	10′6″	10.2
7° taper angle
22H	400	1′3¾″	1.6
22H	800	2′7½″	2.8
22H	1600	5′3″	5.2
22H	1830	6′	6.0
22H	3050	10′	9.7
22H	4000	13′1½″	12.6
11° taper angle
22H	800	2′7½″	2.8
22H	1525	5′	5.0
22H	1830	6′	6.0
22H	3200	10′6″	10.2
22H	4800	15′9″	15.1
12° taper angle
22H	610	2′	2.2
22H	1220	4′	4.1
22H	2000	6′6¾″	6.5
22H	3200	10′6″	10.2
22H	8000	26′3″	24.9

?

Frequently Asked Questions

What are the primary applications of taper drill rods?

Taper drill rods are primarily used for rock drilling, creating blasting holes, and other drilling tasks in quarries, coal mines, and infrastructure construction projects.

How do I choose the correct taper angle for my equipment?

Selection depends on the machine's power: light-duty rock drills typically use a 7° or smaller taper, while heavy-duty rock drills require an 11° or 12° taper angle.

What steel grades are used in your taper rods?

Our rods are manufactured from high-quality steel grades including 95CrMo (equivalent to SANDBAR20/C253), 55SiMnMo, and other durable carbon steel alloys.

Can I use different taper degrees for the rod and the bit?

No. For safe and efficient operation, the taper drill rod and the taper drill bit must have the exact same tapered degree.

What are the standard shank sizes available?

Common shank sizes include Hex 22mm x 108mm and Hex 25mm x 108mm, though we offer various configurations to suit hand-held pneumatic drilling needs.

How are the products packaged for international transport?

Products are securely packed in either wooden cases or bundles to ensure safe delivery and protection during transit.
