High-Quality DHD360 Drill Tools DTH Hammer with Foot Valve Factories, Pricelist

Product Details

Customization:	Available
After-sales Service:	Repair or Replacement
Warranty:	6 Months

Send Inquiry

Product Description

■ Basic Information

Model NO.

DHD360

Certification

CE, ISO 9001:2000, ISO 9001:2008

Standard

AISI, GB

Surface Treatment

Spray-Paint

Manufacturing Process

Stamping

Material

Carbon Steel

Machine Type

Drilling Tools

Color

Red, Black, Yellow, White

Shank Adapter

CIR/DHD/M/Ql/SD

Length

1063mm

Weight

100.5kg

Outer Diameter

142mm

Connection Thread

API3 1/2"Reg

Hole Range

150mm-190mm

Work Pressure

1.0-2.5 MPa

Transport Package

Wooden Case

■ Packaging & Delivery

Package Size

30.00cm * 30.00cm * 30.00cm

Package Gross Weight

5.000kg

Production Capacity

500,000 PCS/Month

■ Product Description

Because of economy and powerful drilling capacity, down the hole hammer become an advanced drilling tool for drilling and mining industries. Down the hole hammers and drill bits are designed together to work in perfect unison, giving high penetration rates, long service life and low costs.

Deliver maximum energy to drilling bit, fast drilling speed and low air consumption.
Smooth performance and long service life due to high quality alloy steel materials.
Low problem rate and easy maintenance due to simple, reliable inner structure.
Easy to depart bit from hammer due to multihead thread connecting chuck.
Interchangeable with DTH bit and drill pipe.

■ Technical Parameters

Length (Less bit)	Weight	Outer Diameter	Connection Thread	Bit Shank	Hole Range
1063mm	100.5Kg	142mm	API3 1/2"REG	DHD360	150-190mm
Work Pressure		Recommended rotation speed		Air Consumption 1.0Mpa	Air Consumption 1.8Mpa
1.0-2.5 Mpa		30-60 r/min		9m³/min	20m³/min
