Bench and production drilling tools include rods, shank adapters, couplings, and bits. We provide a comprehensive range covering 9 main threads: R3212, R32, HL38, T38, T45, T51, T60, ST58, and ST68. These tools are ideally compatible with button bits, cross bits, and reaming products.
Our rock drilling tools range from 1" rope thread equipment up to T60 thread equipment. Engineered for high performance, these drill rods, tubes, and button bits are designed to improve productivity considerably in the most demanding environments.
| Type | Carbide Dimension | Dimensions D | Flushing Hole | |||||
|---|---|---|---|---|---|---|---|---|
| Gauge | Front | |||||||
| No. | mm | No. | mm | mm | inch | Front | Side | |
| Button bit-T45 | 6 | 12.7 | 3 | 12.7 | 76 | 3" | 3 | 1 |
| Button bit-T45 | 6 | 14 | 4 | 14 | 89 | 3 1/2" | 3 | 0 |
| Button bit-T45 | 8 | 12.7 | 5 | 10 | 76 | 3" | 4 | 0 |
| Button bit-T45 | 8 | 14 | 6 | 12.7 | 102 | 4" | 4 | 2 |
| Flat Face | 8 | 11 | 6 | 11 | 76 | 3" | 2 | 0 |
| Flat Face | 8 | 12.7 | 6 | 11 | 82 | 3 1/4" | 2 | 1 |
| Flat Face | 8 | 12.7 | 6 | 12.7 | 89 | 3 1/2" | 2 | 0 |
| Flat Face | 8 | 14 | 6 | 14 | 102 | 4" | 2 | 0 |
| Drop Center | 6 | 14 | 3/2 | 12.7/9.5 | 89 | 3 1/2" | 3 | 0 |
| Drop Center | 8 | 11 | 4/1 | 10/10 | 76 | 3" | 4 | 0 |
