China New Technical H22*108 Forging Type Blast Hole Tapered Rock Drill Rods with Button Bit Manufacturer, Pricelist

Product Details
Customization: Available
After-sales Service: Repair or Replacement
Warranty: 6 Months

Product Description

📋 Basic Info
Model NO.
Hex22 tapered drill rod
Certification
ISO 9001:2000, ISO 9001:2008
Standard
GB
Surface Treatment
Spray-Paint
Manufacturing Process
Forging
Material
Carbon Steel
Degree
7/11/12
Machine Type
Drilling Tools
Color
Red, Black, Yellow, White
Material Quality
95crmo 55simnmo 40simncrnimo 23crni3mo D6a
Length
3 Pies
HS Code
82071990
Specification
Hex22mm Hex25mm
Production Capacity
500000PCS/Month
📦 Packaging & Delivery
Package Size
30.00cm * 30.00cm * 30.00cm
Package Gross Weight
5.000kg
Transport Package
Wooden Case
📝 Product Description

Taper drill rod is used for rock drilling, blasting holes and other drilling works in the quarries, coal mines, traffic and other contractions. It works with taper drill bits and has different length for various applications. Our taper drill rods come in a variety of taper angles. Generally, the light duty rock drill usually use 7 taper or smaller taper angle, while the heavy duty rock drill mainly use 11 or 12 taper angle.

The basic theory is that taper drill rods and taper drill bits must be in the same tapered degree. We provide tapered rods in a full range of shank configurations and steel hex diameters for hand-held pneumatic drilling needs.

Key Specifications:
• Steel grade: 95CrMo equivalent to SANDBAR20 or C253, Z708, sanbar23, 55SiMnMo
• Shank size: hex.22mm×108mm, hex.22mm×159mm, hex.22mm×80mm, hex.25mm×108mm, hex.25mm×159mm
• Taper: 4°46′, 6, 7, 11, 12 degree etc
• Length: 0.4m-10m
• Productivity: 50000MT / month

Shank hex. 22 mm (7/8") x 108 mm (4 1/4"). Rod hex. 22 mm (7/8). Flushing hole diameter 6.7 mm

ROD CROSS SECTION Length (mm / foot-inch) Weight approx. (kg)
4º46′ Taper Angle
22H8002′7½″2.8
22H16005′3″5.3
22H20006′6¾″6.5
22H320010′6″10.2
22H400013′1½″12.7
7º Taper Angle
22H4001′3¾″1.6
22H16005′3″5.2
22H305010′9.7
22H560018′4½″17.5
22H800026′3″24.9
11º Taper Angle
22H8002′7½″2.8
22H18306′6.0
22H365511′11⅝″11.6
22H800026′3″24.9
12º Taper Angle
22H6102′2.2
22H15255′5.0
22H305010′9.7
22H800026′3″-
Frequently Asked Questions
What industries use these tapered drill rods?
Taper drill rods are primarily used in rock drilling, blasting hole creation, coal mining, quarrying, and various traffic-related construction projects.
How do I choose the correct taper angle?
Generally, light-duty rock drills use a 7-degree or smaller taper, while heavy-duty rock drills require 11 or 12-degree taper angles for optimal performance.
What materials are the rods made from?
The rods are manufactured from high-quality carbon steel and alloy grades like 95CrMo (equivalent to SANDBAR20), 55SiMnMo, and 40Simncrnimo.
What shank sizes are available?
Common shank sizes include Hex 22mm x 108mm, Hex 22mm x 159mm, and Hex 25mm x 108mm, covering most hand-held pneumatic drilling needs.
How are the products protected during shipping?
Products are securely packed in wooden cases or bundles to ensure they remain intact and protected from the elements during transport.
Can these rods be used with any drill bit?
The taper drill rod must be paired with a taper drill bit of the same degree (e.g., an 11° rod must use an 11° bit) for a proper and safe fit.
