China Br3 High Wind Pressure Down The Hole Impactor DTH Drilling Hammer Manufacturers, Pricelist

1 / 5

China Br3 High Wind Pressure Down The Hole Impactor DTH Drilling Hammer Manufacturers, Pricelist

Product Details

Customization:	Available
After-sales Service:	Repair or Replacement
Warranty:	6 Months

Send Inquiry

Product Description

Basic Information

Model NO.

BR3 Hammer

Certification

CE, ISO 9001:2000, ISO 9001:2008

Standard

AISI, GB

Surface Treatment

Spray-Paint

Material

Carbon Steel

Machine Type

Drilling Tools

Bit Adapter

Br3

Outside Diameter

82mm

Working Pressure

0.8-1.7MPa

Production Capacity

500000PCS/Month

Product Description

High air pressure DTH hammer is a kind of down-the-hole hammer. It is mainly used for percussive drilling in rock formation. It is characterized by high air pressure and high efficiency. It is suitable for use in areas with abundant air supply. The working principle of the high air pressure DTH hammer is to use compressed air to drive the piston to reciprocate in the cylinder, thereby generating impact energy to impact the drill bit and drill into the rock formation.

Deliver maximum energy to drilling bit, fast drilling speed and low air consumption.
Smooth performance and long service life due to high quality alloy steel materials.
Low problem rate and easy maintenance due to simple, reliable inner structure.
Easy to depart bit from hammer due to multihead thread connecting chuck.
Interchangeable with DTH bit and drill pipe.
Penetrate 15% to 30% faster than conventional hammers.

Technical Specifications

Type	Model	Length(mm)	Weight(kg)	External Dia.(mm)	Hole Range(mm)
3.5 inch	DHD3.5	930	25	Φ82	Φ90-110
4 inch	DHD340	1030	39	Φ99	Φ110-135
5 inch	DHD350	1214	76.5	Φ125	Φ135-155
6 inch	DHD360	1248	100	Φ142	Φ155-190
8 inch	D85	1492	188	Φ180	Φ195-254

Detailed Photos

Packaging & Shipping

Frequently Asked Questions

What are the available payment methods?

We accept T/T (Telegraphic Transfer), Western Union, or L/C at sight.

How long does it take to process an order?

Based on order quantity, normally it takes 25 days for production. If we have the requested size in stock, it only takes 2 to 3 days.

What shipping ways do you offer?

For sample orders, we suggest courier express like DHL/UPS/TNT/FEDEX or by air. For bulk orders, we suggest shipping by air or by sea.

How do you ensure quality control?

We have our own experienced QC team. There will be strict inspection and testing for every order before shipping out.

What after-sales services are provided?

Our sales team will respond to your questions within 24 hours. Technical support is available at any time, and free replacements are provided for confirmed quality failures.

Is the DTH hammer compatible with other equipment?

Yes, our hammers are designed to be interchangeable with standard DTH bits and drill pipes, suitable for high pressure drilling rigs.
