High-Quality 2023 New Technical Forging Type H22*108 Pneumatic Tools Tapered Drill Rod for Hard Rock Drinlling Factory, Factories

Product Details

Customization:	Available
After-sales Service:	Repair or Replacement
Warranty:	6 Months

Send Inquiry

Product Description

📋 Basic Product Information

Model NO.

Tapered drill rod

Certification

ISO 9001:2000, ISO 9001:2008

Standard

Surface Treatment

Spray-Paint

Manufacturing

Forging

Material

Carbon Steel / 95CrMo / 55SiMnMo

Degree

7° / 11° / 12°

Machine Type

Drilling Tools

Color

Red, Black, Yellow, White

Length

0.4m - 10m

HS Code

82071990

Production Cap.

500,000 PCS/Month

📦 Packaging & Delivery

Package Size

30.00cm * 30.00cm * 30.00cm

Gross Weight

5.000kg

Transport

Wooden Case or Bundles

📝 Product Description

Taper drill rod is essentially used for rock drilling, blasting holes, and other drilling works in quarries, coal mines, traffic, and various construction projects. It is designed to work seamlessly with taper drill bits across different applications.

✔ Versatile Application: Ideal for hand-held pneumatic drilling needs in heavy-duty and light-duty environments.

✔ Taper Matching: Available in various angles (7°, 11°, 12°). Ensure the rod and bit share the same degree for optimal performance.

✔ Premium Steel Grades: Manufactured with 95CrMo (equivalent to SANDBAR20/C253) or 55SiMnMo for maximum durability.

Standard Shank Configurations:

• Hex. 22mm × 108mm
• Hex. 22mm × 159mm
• Hex. 22mm × 80mm
• Hex. 25mm × 108mm
• Hex. 25mm × 159mm

📊 Technical Specifications

Rod Cross Section	Length (mm)	Length (Foot/Inch)	Weight Approx. (kg)
4°46′ Taper Angle
22H	800	2′7½″	2.8
22H	1600	5′3″	5.3
22H	2400	7′10½″	7.7
22H	4000	13′1½″	12.7
7° Taper Angle
22H	400	1′3¾″	1.6
22H	1600	5′3″	5.2
22H	3050	10′	9.7
22H	8000	26′3″	24.9
11° Taper Angle
22H	800	2′7½″	2.8
22H	1830	6′	6.0
22H	3655	11′11⅝″	11.6
22H	7200	23′7½″	22.5
12° Taper Angle
22H	610	2′	2.2
22H	1220	4′	4.1
22H	3200	10′6″	10.2
22H	8000	26′3″	24.9

❓ Frequently Asked Questions

Q1: What materials are used for the tapered drill rods?

We use high-quality Carbon Steel and specialized alloys like 95CrMo (equivalent to SANDBAR20 or C253) and 55SiMnMo to ensure high fatigue strength and wear resistance.

Q2: How do I choose the correct taper angle for my project?

Generally, light-duty rock drills use a 7° or smaller taper angle. Heavy-duty rock drills primarily utilize 11° or 12° taper angles. The rod and bit must always match in degree.

Q3: What are the standard shank sizes available?

The most common shank sizes are Hex 22mm x 108mm and Hex 25mm x 159mm. We also offer configurations for 80mm shanks and various other lengths.

Q4: What is the range of lengths you can provide?

We can manufacture tapered drill rods in lengths ranging from 0.4 meters up to 10 meters to suit different drilling depths and equipment requirements.

Q5: What are the typical applications for these rods?

These rods are widely used in granite and marble quarries, coal mining, tunneling, and construction for blasting hole drilling.

Q6: How are the products packaged for international shipping?

To ensure safety during transport, we package the drill rods in sturdy wooden cases or secure bundles, depending on the length and quantity of the order.
